Solar Powered High Liquid Alarm CP1003

The Solar Power High Liquid Alarm will notify maintenance personnel in the event of a high liquid condition. The system is complete with visual indicators and dry contacts to connect to a dialer (optional) or building automation system.


  • Solar cell provides 24/7 continuous power to high liquid alarm panel
  • UL Listed for the United States and Canada
  • Includes Narrow Angle Float Switch with 20’ cord
  • Indoor/Outdoor NEMA 4X panel enclosure: heavy duty polycarbonate with stainless steel lockable latches
  • Includes 10 Watt Multi-Crystalline Solar Panel, 12V, 9.0 Amp Hr. Sealed Rechargeable Battery, and Solar Charger
  • Quick Installation and Low Maintenance
  • High Liquid Alarm with Test and Silence Features, Red Beacon Alarm Light, High 85 Decibel Audible Alarm. Dry Contact for High Liquid Condition
  • Solar Panel Mounting Hardware
  • Easy Accessible Terminal Block


  • Sewage and Wastewater
  • Remote or Rural Containment
  • Flood Zones
  • Industrial Sumps
  • Holding Tanks
  • Residential Tanks
  • Lift Stations
  • Leach Line

Custom Options

  • C = Additional cord length greater than 20’: Specify after C.
    Example: (CP1003-C50) indicates 50’ cable length for narrow angle float.
Get in Touch: 888-733-9283
